SKU: AK12401N
Product Details: Manual operation, with air pilot reset; Detented in the out position; Panel, inline or thru hole mounting; 96 SCFM airflow (atfull open); 200 PSI Max Supply; 40 PSI (Minimum) for Pilot Pressure; Mini Black Knob
Push-Pull Control Valve; 3-WAY; 2 POS; 3/8" NPT 3-Port; w/pilot (Repl Manac SP-4901)
Product Specifications
AK12401N Push-Pull Control Valve; 3-WAY; 2 POS; 3/8" NPT 3-Port; w/pilot (Repl Manac SP-4901)
SKU: AK12401N
Product Details: Manual operation, with air pilot reset; Detented in the out position; Panel, inline or thru hole mounting; 96 SCFM airflow (atfull open); 200 PSI Max Supply; 40 PSI (Minimum) for Pilot Pressure; Mini Black Knob
